產品種類 Main Products
(1) 一般五金零件 (2) 機械零件 (3) 氣動工具零件 (4) 運動器材零件 (5) 釘槍零件 (6) 自行車零件 (7) 食品零件(8) 鑄鐵壺/不銹鋼壺 (9) X型 鋁合金拉環手機護套 (10) 自行車斷鏈/棘輪工具組
Needl machine parts, general types of machine parts, golf club heads, pneumatic tools and food processing machine parts, Cast iron teapot/Stainless steel teapot, X-hold phone cases ,Multi-function Portable Bike Bicycle Repair Tools Kit .
鑄造材質 Applicable Materials
(1) 不銹鋼 (2) 鉬鉻合金鋼 (3) 合金鋼 (4) 碳鋼 (5) 含鋁合金鋼
Carbon steel,alloy steel,tool steel,stainless steel,and aluminum alloy.
傳統鑄造成品群
![](images/p1_1.jpg) ![](images/p1_2.jpg) ![](images/p1_3.jpg) ![](images/p1_4.jpg) ![](images/p1_5.jpg) ![](images/p1_6.jpg) ![](images/p1_7.jpg) ![](images/p1_8.jpg)
真空鑄造成品群
![](images/p2_1.jpg) ![](images/p2_2.jpg) ![](images/p2_3.jpg) ![](images/p2_4.jpg) ![](images/p2_5.jpg) ![](images/p2_6.jpg) ![](images/p2_7.jpg) ![](images/p2_8.jpg)
成品區(點選圖片進入)
![鑄鐵壺](images/fp_01.jpg) ![鑄鐵壺](images/fp_02.jpg) ![手機殼](images/fp_03.jpg) ![工具組](images/fp_04.jpg)
脫腊鑄造鑄件估價要求及時間
估價需求 Quotation
(1) 客戶提供2D圖或3D圖檔 (2) 實體樣品
要求 Customer Requirements
(1) 所有重要外觀、尺寸及表面處理之需求 (2) 加工部位及加工量 (3) 工件檢查規範
尺寸公差(常用公差範圍) Dimensional Tolerances
A、毫米(mm)
尺寸
Dimnsions(mm) |
0~5 |
5~10 |
10~25 |
25~50 |
50~75 |
75~100 |
100~125 |
125~150 |
150~175 |
175~200 |
200~250 |
一般公差
(Normal) |
±0.25 |
±0.40 |
±0.60 |
±0.80 |
±1.1 |
±0.1.4 |
±0.1.7 |
±2.0 |
±2.5 |
特別公差
(Premiun) |
±0.07 |
±0.14 |
±0.25 |
±0.32 |
±0.50 |
±0.70 |
±0.90 |
±1.10 |
±1.30 |
±1.50 |
±1.80 |
尺寸
Dimnsions(mm) |
一般公差
(Normal) |
特別公差
(Premiun) |
0~5 |
±0.25 |
±0.07 |
5~10 |
±0.14 |
10~25 |
±0.25 |
25~50 |
±0.40 |
±0.32 |
50~75 |
±0.60 |
±0.50 |
75~100 |
±0.80 |
±0.70 |
100~125 |
±1.1 |
±0.90 |
125~150 |
±0.1.4 |
±1.10 |
150~175 |
±0.1.7 |
±1.30 |
175~200 |
±2.0 |
±1.50 |
200~250 |
±2.5 |
±1.80 |
B、英寸(in)
尺寸
Dimnsions(mm) |
0~0.2 |
0.2~0.4 |
0.4~1.0 |
1.0~2.0 |
2.0~3.0 |
3.0~3.9 |
3.9~4.9 |
4.9~5.9 |
5.9~6.9 |
6.9~7.9 |
7.9~9.8 |
一般公差
(Normal) |
±0. |
±0.016 |
±0.024 |
±0.031 |
±0.043 |
±0.055 |
±0.067 |
±0.079 |
±0.098 |
特別公差
(Premiun) |
±0.003 |
±0.006 |
±0.010 |
±0.013 |
±0.020 |
±0.028 |
±0.035 |
±0.043 |
±0.051 |
±0.059 |
±0.071 |
尺寸
Dimnsions(mm) |
一般公差
(Normal) |
特別公差
(Premiun) |
0~0.2 |
±0. |
±0.003 |
0.2~0.4 |
±0.006 |
0.4~1.0 |
±0.010 |
1.0~2.0 |
±0.016 |
±0.013 |
2.0~3.0 |
±0.024 |
±0.020 |
3.0~3.9 |
±0.031 |
±0.028 |
3.9~4.9 |
±0.043 |
±0.035 |
4.9~5.9 |
±0.055 |
±0.043 |
5.9~6.9 |
±0.067 |
±0.051 |
6.9~7.9 |
±0.079 |
±0.059 |
7.9~9.8 |
±0.098 |
±0.071 |
平直度(一般公差) Flatness Tolerances
公制(mm) |
英制(吋) |
公制(mm) |
英制(吋) |
小於 50 ± 0.25 |
小於 2.0" ± 0.010" |
100~150 ± 0.50 |
4.0" ± 0.020" |
50~100 ± 0.38 |
2.0"~4.0" ± 0.015" |
150~2000 ± 0.75 |
6.0"~8.0" ± 0.030" |
角度公差 Angle Tolerance
通常 ± 1°,勿小於 1/2°
內外R角 Inside and Outside R Angle
(1) 增加鑄件機械性能 (2) 較佳的鑄造流動性 (3) 理想R角 0.5mm~1.5mm
開發產品時間表 Timetable
名稱 |
時間 |
模具製作 |
15~21天 |
送客戶鑄件樣品 |
7~10天 |
第一批試量產 |
15~30天 |
正常交貨 |
30~40天 |
特急交貨 |
15~30天 |
|
